Model

Performance parameters

Technical parameters


RL-06C

Standard 2 ~ 8 ℃ refrigerator for 48 hours, and optional LCD temperature display, up to 72 hours can be increased with

【Outside Size】325 × 265 × 300mm
【Within Size】235 × 145 × 180mm

【Effective space】
155 × 105 × 27 ~ 180mm high

【Weight】 2.0KG
【empty Tank Capacity】6L

【insulation Materials】 PU polyurethane

Overall foaming molding process

RL-06D

Standard -12 ~ -18 ℃ freezer 36 hours, and optional LCD temperature display, up to 60 hours can be increased with

RL-06S

Standard -30 ~ -55 ℃ freezer for 12 hours, and optional LCD temperature display, with a maximum increase to 36 hours.

RL-06SK

Standard 2 ~ 8 ℃ refrigerator for 48 hours, 0 ℃ following environment-specific, to avoid freezing of samples.

RL-07C

Standard 2 ~ 8 ℃ refrigerator for 24 hours for up to 48 hours was equipped with

【Outside Size】325 × 220 × 210mm
【Within Size】230 × 185 × 170mm

【Weight】 1.4KG

【air tank volume】7L

EPS polystyrene insulation material Sandwich molding molding process

RL-07D

Standard -12 ~ -18 ℃ freezer 8 hours, for up to 24 hours was equipped with

RL-10C

Standard 2 ~ 8 ℃ refrigerator 36 hours, and optional LCD temperature display, up to 54 hours can be increased with

【Outside Size】 400 × 220 × 275mm
【Within Size】330 × 175 × 205mm

【Weight】 2.2KG

【air tank volume】10L

PU polyurethane insulation materials,Overall foaming molding process

RL-10D

Standard -12 ~ -18 ℃ freezer 18 hours, and optional LCD temperature display, up to 48 hours can be increased with

RL-10S

Standard -30 ~ -55 ℃ freezer for 12 hours, and optional LCD temperature display, with a maximum increase to 24 hours.

RL-10K

Standard 2 ~ 8 ℃ refrigerator for 48 hours, 0 ℃ following environment-specific, to avoid freezing of samples.

RL-12AC

Standard 2 ~ 8 ℃ for 48 hours refrigerated, box locks, and optional LCD temperature display, up to 72 hours can be increased with

【Outside Size】400 × 290 × 285mm
【Within Size】320 × 205 × 210mm

【Weight】 3.0KG empty

【air tank volume】 12L

PU polyurethane insulation materials,Overall foaming molding process

RL-12AD

Standard -12 ~ -18 ℃ to 36 hours refrigerated, box locks, and optional LCD temperature display, up to 48 hours can be increased with

RL-12BC

Standard 2 ~ 8 ℃ refrigerator for 24 hours for up to 36 hours was equipped with

【Outside Size】390 × 215 × 270mm
【Within Size】320 × 160 × 205mm

【Weight】 1.8KG

【air tank volume】 12L

EPS polystyrene insulation material,Sandwich molding process

RL-12BD

Standard -12 ~ -18 ℃ freezer for 12 hours, for up to 18 hours was equipped with

RL-13C

Standard 2 ~ 8 ℃ refrigerator for 48 hours, and optional LCD temperature display, up to 72 hours can be increased with

【Outside Size】400 × 290 × 285mm
【Within Size】320 × 205 × 210mm

【Weight】 2.4KG

【air tank volume】13L

PU polyurethane insulation materials,Overall foaming molding process

RL-13D

Standard -12 ~ -18 ℃ freezer 36 hours, and optional LCD temperature display, up to 48 hours can be increased with

RL-13S

Standard -30 ~ -55 ℃ freezer for 12 hours, and optional LCD temperature display, with a maximum increase to 36 hours.

RL-13K

Standard 2 ~ 8 ℃ refrigerator for 48 hours, 0 ℃ following environment-specific, to avoid freezing of samples.

RL-16C

Standard 2 ~ 8 ℃ refrigerator for 24 hours for up to 48 hours was equipped with

【Outside Size】380 × 220 × 375mm
【Within Size】310 × 180 × 280mm

【Weight】 2.8KG

【air tank volume】17L

PU polyurethane insulation material,Overall foaming molding process

RL-16D

Standard -12 ~ -18 ℃ freezer for 12 hours, for up to 24 hours was equipped with

RL-17BC

Standard 2 ~ 8 ℃ refrigerator for 24 hours for up to 48 hours was equipped with

【Outside Size】435 × 300 × 320mm
【Within Size】340 × 200 × 245mm

【Weight】 2.6KG

【air tank volume】17L

EPS polystyrene insulation material,Sandwich molding process

RL-17BD

Standard -12 ~ -18 ℃ freezer for 12 hours, for up to 24 hours was equipped with

RL-17AC

Standard 2 ~ 8 ℃ for 48 hours refrigerated, box locks, and optional LCD temperature display, up to 96 hours can be increased with

【Outside Size】420 × 280 × 330mm
【Within Size】340 × 200 × 250mm
【Effective space】
230 × 140 × 27 ~ 250mm high

【Weight】 3.8KG

【air tank volume】17L
PU polyurethane insulation materials,Overall foaming molding process

RL-17AD

Standard -12 ~ -18 ℃ to 36 hours refrigerated, box locks, and optional LCD temperature display, up to 72 hours can be increased with

RL-17AS

Standard -30 ~ -55 ℃ freezer for 12 hours, and optional LCD temperature display, with a maximum increase to 48 hours.

RL-17AK

Standard 2 ~ 8 ℃ refrigerator for 48 hours, 0 ℃ following environment-specific, to avoid freezing of samples.

RL-28BC

Standard 2 ~ 8 ℃ refrigerator 36 hours, and optional LCD temperature display, up to 48 hours can be increased with

【Outside Size】430 × 290 × 440mm

【Within Size】370 × 230 × 400mm

【Weight】 3KG

【air tank volume】28L

PU polyurethane insulation materials,Overall foaming molding process

RL-28BD

Standard -12 ~ -18 ℃ freezer for 12 hours, and optional LCD temperature display, up to 24 hours can be increased with

RL-28AC

Standard 2 ~ 8 ℃ refrigerator for 48 hours, and optional LCD temperature display, up to 72 hours can be increased with

【Outside Size】550 × 340 × 360mm

【Within Size】435 × 250 × 260mm

【Weight】 5.8KG

【air tank volume】28L

PU polyurethane insulation materials,Overall foaming molding process

RL-28AD

Standard -12 ~ -18 ℃ freezer 36 hours, and optional LCD temperature display, up to 48 hours can be increased with

RL-33C

Standard 2 ~ 8 ℃ for 48 hours refrigerated, box locks, and optional LCD temperature display, up to 72 hours can be increased with

【Outside Size】605 × 340 × 420mm
【Within Size】525 × 250 × 340mm

【Weight】 6.0KG

【air tank volume】33L

PU polyurethane insulation materials,Overall foaming molding process

RL-33D

Standard -12 ~ -18 ℃ to 36 hours or more frozen, box locks, and optional LCD temperature display, up to 48 hours can be increased with

RL-46AC

Standard 2 ~ 8 ℃ for 48 hours refrigerated, box locks, and optional LCD temperature display, up to 80 hours can be increased with

【Outside Size】605 × 340 × 420mm
【Within Size】525 × 250 × 340mm

【Weight】 6.0KG

【air tank volume】46L

PU polyurethane insulation materials,Overall foaming molding process

RL-46AD

Standard -12 ~ -18 ℃ to 36 hours or more frozen, box locks, and optional LCD temperature display, up to 60 hours can be increased with

RL-48C

2 ~ 8 ℃ standard 24-hour cold storage, optional LCD temperature display, up to 48 hours can be increased with

【Outside Size】 605 × 340 × 420mm
【Within Size】540 × 280 × 300mm

【Weight】 6.0KG

【air tank volume】48L

PU polyurethane insulation materials,Overall foaming molding process

RL-48D

Standard -12 ~ -18 ℃ freezer 16 hours, and optional LCD temperature display, up to 24 hours can be increased with

RL-50C

Standard 2 ~ 8 ℃ refrigerator for 48 hours, and optional LCD temperature display, up to 72 hours can be increased with

【Outside Size】615 × 410 × 390mm
【Within Size】535 × 330 × 315mm

【Weight】 6.5KG

【air tank volume】50L

PU polyurethane insulation materials,Overall foaming molding process

RL-50D

Standard -12 ~ -18 ℃ freezer 36 hours, and optional LCD temperature display, up to 48 hours can be increased with

RL-71C

Standard 2 ~ 8 ℃ refrigerator 36 hours, and optional LCD temperature display, up to 48 hours can be increased with

【Outside Size】790 × 500 × 420mm
【Within Size】580 × 360 × 340mm

【Weight】 9.0KG

【air tank volume】71L

PU polyurethane insulation materials,Overall foaming molding process

RL-71D

Standard -12 ~ -18 ℃ freezer 24 hours, and optional LCD temperature display, up to 36 hours can be increased with

RL-80C

Standard 2 ~ 8 ℃ refrigerator 36 hours, and optional LCD temperature display, up to 48 hours can be increased with

【Outside Size】700 × 440 × 450mm

【Within Size】550 × 340 × 370mm

【Weight】 8.4KG

【air tank volume】80L

PU polyurethane insulation materials,Overall foaming molding process

RL-80D

Standard -12 ~ -18 ℃ frozen 324 hours or more, optional LCD temperature display, up to 48 hours can be increased with

RL-100C

Standard 2 ~ 8 ℃ refrigerator 36 hours, and optional LCD temperature display, up to 48 hours can be increased with

【Outside Size】750 × 460 × 440mm

【Within Size】640 × 390 × 390mm

【Weight】 9.5KG

【air tank volume】100L

PU polyurethane insulation materials,Overall foaming molding process

RL-100D

Standard -12 ~ -18 ℃ frozen more than 24 hours, and optional LCD temperature display, up to 48 hours can be increased with

RL-110C

Standard 2 ~ 8 ℃ refrigerator for 48 hours, and optional LCD temperature display, up to 72 hours can be increased with

【Outside Size】680 × 500 × 540mm

【Within Size】600 × 420 × 440mm

【Weight】 10.0KG

【air tank volume】110L

PU polyurethane insulation materials,Overall foaming molding process

RL-110D

Standard -12 ~ -18 ℃ freezer 36 hours or more, optional LCD temperature display, up to 60 hours can be increased with

RL-04C

Standard 2 ~ 8 ℃ more than 12 hours

【Outside Size】285 × 185 × 200mm

【Within Size】240 × 140 × 140mm

【Weight】 0.9KG

【air tank volume】 4L

EPS polystyrene insulation material,Sandwich molding molding process

RL-04D

Standard -12 ~ -18 ℃ freezer 8 hours

RL-3C

Standard 2 ~ 8 ℃ more than 12 hours

【Outside Size】260 × 150 × 200mm

【Within Size】220 × 115 × 160mm

【Weight】 0.5KG

【air tank volume】3L

EPS polystyrene insulation material,Sandwich molding molding process

RL-3D

Standard -12 ~ -18 ℃ freezer 8 hours

Ice pack

Standard 2 ~ 8 ℃ more than 10 hours

【Outside Size】220 × 150 × 150mm

【Within Size】210 × 140 × 140mm

【air tank volume】4L

【insulation materials

】 Sandwich molding molding process

Size can be customized according to customer requirements, design or printing
